8 channels Wired Underfloor Heating Central Controller

8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller
8 channels Wired Underfloor Heating Central Controller

8 channels Wired Underfloor Heating Central Controller

The HR-02C is a 8 zone wired floor heating controller.  This wired wiring regulators used to control any actuator or valve which requires a 230v AC signal. At the same time it offers the ability to operate a boiler through a volt free output. Up to 5 thermal actuators can be connected to each zone.

  • Item No.: HR-02
  • Controlling up to 40 thermoelectric actuators with the use of 8 output. ( each output max.  5 actuators)
  • Can work up to Max 8 room thermostats
  • One 230Vac output for a circulation pump
  • One voltage-free realy to contraol an additional heating device ( gas boiler or heat pump)
  • Convenient wiring and installation
  • DIN rail function
  • Terminals for wiring

Underfloor heating systems are very effective and economical way of heating your home. It allow you to have a greater heating comfort with real savings. To talk about savings you need one system that will regulate the amount of heat delivered to the rooms. Floor heating control wired controller are specialized, modern devices that support the management and control of temperature in each room separately. The use of 8 zones  floor heating controllers is time-saving and ensure full thermal comfort in whole house.
