This touch EC fan coil thermostat is designed to control fans, valves, dampers or electric heaters in fan coil units and HVAC systems, supporting intelligent building automation via BACnet protocol for industrial, commercial and residential environments.
This digital factory wholesale fan coil unit thermostat is designed to control the fans, valves, dampers or electric heater in fan coil units and heating applications. Such touch BACnet & Modbus FCU thermostat detects the room temperature with its integrated temperature sensor and compares it with the setpoint temperature. In the event of a deviation, the heating valve is opened in heating mode, and the cooling valve is opened in cooling mode. At the same time, the connected fan is activated depending on the control deviation and the set configuration. A connectable remote sensor can be used either for detecting the room temperature or as a changeover sensor in 2-pipe system or 4-pipe system
Equipped with standard BACnet MS/TP communication protocol, this thermostat realizes seamless access to building automation systems (BAS), enabling centralized monitoring, real-time data feedback, unified scheduling and remote group control for large-scale HVAC projects. It features high compatibility, stable transmission and strong anti-interference performance, perfectly adapting to intelligent building, hotel and commercial central control systems.
To better integrate with smart home system, this smart fcu thermostat also workable with tuya wifi. By connecting to home router, this intelligent BACnet & RS485 fcu thermostat will be controlled from anytime anywhere, providing efficient, reliable and energy-saving HVAC management for various scenarios.
| Display | LCD display |
| Protocol | WIFI, Zigbee, Modbus,RS485, Bacnet |
| Power Supply | AC24V or AC85-260V |
| Pipe | 2 Pipes/ 4 Pipes |
| Set Temp. Range | 5~35 ℃ |
| Ambient Temp. | 0~50 ℃ |
| Relative Humidity | 85% |
| Accurancy | ±0.5 ℃ |
| Modes | Cool/Heat/Heat&Cold/Fan Mode |
| Fan Speed | 3 Fan Speeds Select & Auto Fan |
| 0-10V Modulating Control | 0-10V for Valve Control/ Fan Speed Control |
| Programmability | 7 days 4 periods ( Customizable) |
| Optional Function | Clock, Keycard, External Sensor etc. |
| Protection Class | IP20 |
| Thermostat Dimension | 86X86X16.8mm |
| Material | ABS+PC (Rohs certificated) |
| Certificate | CE(RED/EMC/LVD), Rohs |
| OEM & ODM | 1. Customized logo and package |
| 2. Customzied software ( change to customer’s user interface and control logic) | |
| 3. Customized hardware ( change the PCB and schematic based on the request) |
Q: Are you manufacturer?
A:Yes. E-TOP is a professional ODM&OEM Thermostat manufacturer since 2003.
Q: Can i put my brand logo on thermostats?
A: Yes. It’s free when MOQ 500pcs.
Q: Can i have custimized packing box?
A: Yes. MOQ 1000pcs.
Q: What’s the delivery time after i place the order?
A: In 3 working days for samples and 25 days for mass production.
Q: What’s the warranty?
A: 1 year.
Q: Is the thermostat wifi control?
A: Yes. It’s smart phone app control, compatible with Android and IOS.
Q: Does the thermostat support Amazon Alexa and Google Assisstant?
A: Yes.
This touch EC fan coil thermostat is designed to control fans, valves, dampers or electric heaters in fan coil units and HVAC systems, supporting intelligent building automation via BACnet protocol for industrial, commercial and residential environments. Item No.: FT-66 Valve control via 2-point (on/off output) or 0…10 V output Supports 3-speed fans or fans with EC motor Non-Volatile memory to keep program settings and setpoints during a power outage BACnet MS/TP & Modbus/RTU dual protocol management control (Optional) 7 days 4 periods programmable (Optional) Child Lock (Optional) External Sensor (Optional) Keycard (Optional) WIFI Remote Control (Optional)
