Next-Generation Color Touch UI for Modern Spaces

Compared to traditional digital LCD thermostats, the HT-CS08 represents a significant leap in user experience. The 4-inch touch-screen color display not only offers intuitive tactile control but also serves as a modern home decor feature. Users can effortlessly set and adjust the target temperature using a responsive sliding temperature bar. This level of usability makes it a premium choice for modern Heating Control Solutions.

Winter and Summer Mode Smart Thermostat HT-CS08

Seamless Tuya WiFi & Voice Control Integration

Designed for the modern IoT ecosystem, the HT-CS08 belongs to our advanced line of WIFI Thermostats powered by the Tuya cloud platform. It allows users to monitor and control their electric underfloor heating remotely via their smartphone app. Furthermore, it fully supports voice commands and is seamlessly compatible with Google Assistant and Amazon Alexa, providing a hands-free smart home experience.

E-Top HT-CS08 room thermostat function list and technical features

Deep Customization & B2B Brand Solutions

As an industry-leading manufacturer since 2003, E-TOP offers extensive OEM and ODM customization capabilities. From custom brand logos and bespoke packaging to modified software interfaces and underlying control logic, we tailor the HT-CS08 to fit your exact project requirements. If you want to customize your proprietary screen layout, check out our guide on how we deliver custom TFT thermostat UI solutions in just 3 days. Explore our comprehensive Thermostat OEM & ODM Solutions to see how we can elevate your brand.

HT-CS08 programmable smart thermostat color touch screen interface

Certifications & Global Compliance

Our HT-CS08 controller is engineered to meet the highest international standards for safety, reliability, and environmental responsibility:

Safety & EMC: Fully compliant with CE (RED/LVD/EMC), UKCA, FCC, and ETL Listed standards.
Environmental: Certified by RoHS and REACH, ensuring lead-free and eco-friendly manufacturing.
Quality Management: Produced in an ISO 9001:2015 and ISO 14001:2015 certified facility.

Technical Parameter

Display	LCD display
Protocol	WIFI, Zigbee, Modbus, RS485, Bacnet
Power Supply	230Vac, 50/60Hz
Set Temp. Range	5~35 ℃
Ambient Temp.	0~50 ℃
Relative Humidity	85%
Accuracy	±0.5 ℃
Backlight	White/Black
Sensor	NTC 10K
Programmability	7 days 4 periods (Customizable)
Optional Function	Winter/Summer input
Protection Class	IP30
Max Load	3A
Material	ABS+PC (RoHS certified)
Certificate	CE (RED/EMC/LVD), RoHS
Housing	ABS to UL94-5 fire retardant plastic
OEM & ODM	1. Customized logo and package
	2. Customized software (change to customer’s user interface and control logic)
	3. Customized hardware (change the PCB and schematic based on the request)

Dimensions & Installation

Electric Underfloor Heating Room Thermostats Dimensions

Frequently Asked Questions

Q1: What is the difference between water underfloor heating thermostats and electric heating thermostats?

A: Water underfloor heating thermostats typically control thermal actuators, motorized valves, or gas boilers, requiring a 3A relay load with potential-free or dry-contact outputs. In contrast, electric floor heating thermostats must handle direct heating mats and cables, requiring a heavy-duty 16A load capacity. E-TOP manufactures robust solutions for both application types.

Q2: Can E-TOP's water heating thermostats be integrated with multi-zone wiring centres?

A: Yes. Our water floor heating thermostats (including models like HT-70, HT-66, and our modular color touch series) are fully compatible with centralized HVAC Wiring Centres. This enables synchronized multi-room thermal management for residential and commercial underfloor systems.

Q3: Do you offer custom UI and protocol development for water heating projects?

A: Absolutely. Beyond standard Tuya WiFi or Zigbee options, we provide deep software and hardware ODM customization. To see how we streamline brand customization, check out our guide on custom TFT thermostat UI solutions.
