HR-02 wiring centre is designed to be used in conjunction with our wireless thermostats. 8 zones or 16 zones can be controlled as well as providing an output for circulation pump and boiler. Up to 5 thermal actuators can be connected to each zone.
Our underfloor heating wiring centres have been designed to simplify the wiring process. Using our wiring centres in your application means that the actuator, boiler and pump connections are wired from a single point. HR-02 is used in conjunction with our wireless thermostats. 8 zones or 16 zones can be controlled as well as providing an output for circulation pump and boiler. Up to 5 thermal actuators can be connected to each zone.
| Name | Multi-zone Wireless Wiring Centre for Underfloor Heating |
| Power Supply | 230Vac |
| Boiler Output | Voltage-free |
| Pump Output | 230Vac |
| Max. Current | 5(2) A for each |
| Frequency | 868mhz work with RF thermostats |
| Relative Humidity | 85% |
| Accurancy | ±0.5 ℃ |
| Protection Class | IP20 |
| Thermostat Dimension | 353.5mm x 118.4mm x 59.5mm. |
| Materils | ABS+PC (Rohs certificated) |
| Certificate | CE(RED/EMC/LVD), Rohs |
| OEM | 1. Customized logo and package |
| 2. Customzied software ( change to customer’s user interface and control logic | |
| 3. Customized hardware ( change the PCB and schematic based on the request) |
Size:
Installation:
Q: Are you manufacturer?
A:Yes. ETOP is a professional ODM&OEM Thermostat manufacturer since 2003.
Q: Can i put my brand logo on thermostats?
A: Yes. It’s free when MOQ 500pcs.
Q: Can i have custimized packing box?
A: Yes. MOQ 1000pcs.
Q: What’s the delivery time after i place the order?
A: In 3 working days for samples and 25 days for mass production.
Q: What’s the warranty?
A: 1 year.
Q: Is the thermostat wifi control?
A: Yes. It’s smart phone app control, compatible with Android and IOS.
Q: Does the thermostat support Amazon Alexa and Google Assisstant?
A: Yes.
HR-02 wiring centre is designed to be used in conjunction with our wireless thermostats. 8 zones or 16 zones can be controlled as well as providing an output for circulation pump and boiler. Up to 5 thermal actuators can be connected to each zone. Item No.: HR-02 Can work up to 16 room thermostats Max. 16 thermal actuator connectors. Boiler and Pump delay time settable Convenient wiring and installation WIFI Connection ( Optional) Opentherm connection (Optional)
