E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor

E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor
E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor
E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor
E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor
E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor
E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor
E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor
E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor

E-top new arrival EC fan coil HVAC thermostat with RS485 modbus, keycard, external sensor

This toch EC fan coil thermostat is designed to control the fans, valves, dampers or electric heater in fan coil units and heating applications in industrial, commercial or residential environment.

    • Item No.:FT-66


    Valve control via 2-point(on/off output) or 0…10 V output

  • Supports 3-speed fans or fans with EC motor
  • Non-Volatile memory to keep program settings and setpoints during a power outage
  • Modbus/RTU management control (Optional)
  • 7 days 4 perioods programmable (Optional)
  • Child Lock (Optional)
  • External Sensor  (Optional)
  • Keycard  (Optional)
  • WIFI Remote Control (Optional)

This digital  factory wholesale fan coil unit thermostat is designed to controls the fans, valves, dampers or electric heater in fan coil units and heating applications. Such touch modbus FCU thermostat detects the room temperature with its integrated temperature sensor and compares it with the setpoint temperature. In the event of a deviation, the heating valve is opened in heating mode, and the cooling valve is opened for cooling mode. At the same time, the connected fan is activated depending on the control deviation and the set configuration. A connectable remote sensor can be used either for detecting the room temperature or as a changeover  sensor in 2-pipe system or 4 -pipe system.



To better intergrate with smart home system, this smart fcu thermostat also workable with tuya wifi.  By connecting to home router, this intelligent rs485 fcu thermostat will be controlled from anytime anywhere.



Product Display:



Display LCD display
Protocol WIFI, Zigbee, Modbus,RS485, Bacnet
Power Supply AC24V or AC85-260V
Pipe 2 Pipes/ 4 Pipes
Set Temp. Range 5~35 ℃
Ambient Temp. 0~50 ℃
Relative Humidity 85%
Accurancy ±0.5 ℃
Modes Cool/Heat/Heat&Cold/Fan Mode
Fan Speed 3 Fan Speeds Select & Auto Fan
0-10V Modulating Control 0-10V for Valve Control/ Fan Speed Control
Programmability 7 days 4 periods ( Customizable)
Optional Function Clock, Keycard, External Sensor etc.
Protection Class IP20
Thermostat Dimension 86X86X16.8mm
Material ABS+PC (Rohs certificated)
Certificate CE(RED/EMC/LVD), Rohs
OEM & ODM 1. Customized logo and package
2. Customzied software ( change to customer’s user interface and control logic)
3. Customized hardware ( change the PCB and schematic based on the request)

E-top fan coil thermostat

Q: Are you manufacturer?
A:Yes. E-TOP is a professional ODM&OEM Thermostat manufacturer since 2003.

Q: Can i put my brand logo on thermostats?
A: Yes. It’s free when MOQ 500pcs.

Q: Can i have custimized packing box?
A: Yes. MOQ 1000pcs.

Q: What’s the delivery time after i place the order?
A: In 3 working days for samples and 25 days for mass production.

Q: What’s the warranty?
A: 1 year.

Q: Is the thermostat wifi control?
A: Yes. It’s smart phone app control, compatible with Android and IOS.

Q: Does the thermostat support Amazon Alexa and Google Assisstant?
A: Yes.
