TR-01 Zigbee is a smart zigbee e-TRV that gives you easy in-home control of each individual radiator. By adding a Zigbee & WIFI gateway, you can control your radiators from smartphone anytime anywhere.
buttons.
Many homes already have thermostatic radiator valves (or TRVs for short) on their radiators. They work by detecting the temperature of the room, and turn the radiator on or off depending on whether the room needs heating up or not. Having TRVs installed on your radiators allows you to set the temperature in individual rooms. This makes it easier for you to keep rooms at a consistent and comfortable temperature and save on heating bills by only heating the rooms you need to. The function of a smart radiator valve (or SRV for short) is exactly the same, but with these four key advantages:
As TR-01 is battery power supply, for wifi remote control function, a RF&WIFI gateway is necessary.
A gateway max. support 16 pcs TRVs.
TR-01 smart radiator thermostat comes with 6 different adaptors.
| Name | Smart Radiator Thermostat |
| WiFi Application | TuyaSmart, Smart Life, Ecohome Life ( Tuya cloud) |
| WIFI | 2.4G( Don’t support 5G) |
| TR-01 Power Supply | 2*AA battery |
| Gateway Power Supply | 5V/1A USB |
| Frequency | Zigbee work with gateway |
| Set Temp. Range | 5~35 ℃ |
| Ambient Temp. | 0~50 ℃ |
| Frost Protection Temp. | 5 ℃ ~15℃ |
| Sensor Select | Internal sensor |
| Sensor Type | NTC β=3950 R25℃=10KΩ |
| Relative Humidity | 85% |
| Accurancy | ±0.5 ℃ |
| Modes | MAN/Holiday/PRG Mode |
| Programmability | 7 days 4 periods ( Customizable) |
| Window Open Detection | Yes |
| Child Lock | Yes |
| Protection Class | IP20 |
| Thermostat Dimension | φ55*69mm |
| Materils | ABS+PC (Rohs certificated) |
| Certificate | CE(RED/EMC/LVD), Rohs |
| OEM | 1. Customized logo and package |
| 2. Customzied software ( change to customer’s user interface and control logic | |
| 3. Customized hardware ( change the PCB and schematic based on the request) |
Q: Are you manufacturer?
A:Yes. ETOP is a professional ODM&OEM Thermostat manufacturer since 2003.
Q: Can i put my brand logo on thermostats?
A: Yes. It’s free when MOQ 500pcs.
Q: Can i have custimized packing box?
A: Yes. MOQ 1000pcs.
Q: What’s the delivery time after i place the order?
A: In 3 working days for samples and 25 days for mass production.
Q: What’s the warranty?
A: 1 year.
Q: Is the thermostat wifi control?
A: Yes. It’s smart phone app control, compatible with Android and IOS.
Q: Does the thermostat support Amazon Alexa and Google Assisstant?
A: Yes.
TR-01 Zigbee is a smart zigbee e-TRV that gives you easy in-home control of each individual radiator. By adding a Zigbee & WIFI gateway, you can control your radiators from smartphone anytime anywhere. buttons. Item No.: TR-01 Zigbee 7 days 4 periods programmable(from app only) Smart wifi remote control Amazon Alexa and Google Assistant voice control Zigbee work with gateway Child lock Frost protection Open window detection
